Sale!
0.9 to 1.39″ Expansion Dia, 5,900 Lb Holding Force, 8-32 Mounting Screw, 1/2-13 Center Screw, Mild Steel ID Expansion Clamps
Original price was: 76,00 $.53,89 $Current price is: 53,89 $.
Specifications
| Torque (Ft/Lb): 120.0000 | Holding Force (Lb.): 5900.00 |
| Holding Force: 5900 lb | Flange Diameter (Decimal Inch): 2.2050 |
| Maximum Expansion Diameter: 1.39 in | Maximum Expansion Diameter (Decimal Inch): 1.3900 |
| Minimum Expansion Diameter (Decimal Inch): 0.9000 | Minimum Expansion Diameter: 0.9 in |
| Flange Thickness (Decimal Inch): 0.2500 | Expansion Height (Decimal Inch): 0.8100 |
| Height Above Flange (Decimal Inch): 1.0000 | Overall Height (Decimal Inch): 1.2500 |
| Center Screw Thread Size: 1/2-13 | Mounting Screw Thread Size: 8-32 |
| Material: Mild Steel | Mount Hole Diameter (Decimal Inch): 1.7900 |
| Number Of Mount Holes: 3 | Thread Length Below Base (Decimal Inch): 0.7100 |
| Features: For Additional Rigidity Install Recessed Dowel Pin in to Flange | UNSPSC Code: 27112100 |
| Country of Origin: UNITED STATES | |
| Torque (Ft/Lb): 120.0000 | |
| Holding Force (Lb.): 5900.00 | |
| Holding Force: 5900 lb | |
| Flange Diameter (Decimal Inch): 2.2050 | |
| Maximum Expansion Diameter: 1.39 in | |
| Maximum Expansion Diameter (Decimal Inch): 1.3900 | |
| Minimum Expansion Diameter (Decimal Inch): 0.9000 | |
| Minimum Expansion Diameter: 0.9 in | |
| Flange Thickness (Decimal Inch): 0.2500 | |
| Expansion Height (Decimal Inch): 0.8100 | |
| Height Above Flange (Decimal Inch): 1.0000 | |
| Overall Height (Decimal Inch): 1.2500 | |
| Center Screw Thread Size: 1/2-13 | |
| Mounting Screw Thread Size: 8-32 | |
| Material: Mild Steel | |
| Mount Hole Diameter (Decimal Inch): 1.7900 | |
| Number Of Mount Holes: 3 | |
| Thread Length Below Base (Decimal Inch): 0.7100 | |
| Features: For Additional Rigidity Install Recessed Dowel Pin in to Flange | |
| UNSPSC Code: 27112100 | |
| Country of Origin: UNITED STATES |
| MSC# | 68080993 |
| Mfr# | 31250 |
| Big Book# | 1330 |
