9″ Toolroom Lathe: Geared Head, 1 hp, 115 V
132,99 $
Specifications
| Lathe Type: Toolroom | Horse Power: 1 |
| Phase: Single | Voltage: 115V |
| Swing (Inch): 9 | Bed Width (Inch): 9.0000 |
| Spindle Speed Control: Geared Head | Spindle Bore Diameter (mm): 26.00 |
| Cross Slide Travel (mm): 109.98 | Gap Length (Decimal Inch): 20.0000 |
| Bed Width (Inch): 9 | Gap Length (mm): 508.00 |
| Maximum Metric Pitch (Decimal Inch): 12.0000 | Overall Length (mm): 1250.00 |
| Minimum Spindle Speed: 125 | Maximum Spindle Speed (RPM): 2000 |
| Overall Depth (Inch): 23 | Overall Depth (Decimal Inch): 23.0000 |
| Overall Depth (Mm): 584.20 | Overall Height (mm): 475.00 |
| Overall Length (Decimal Inch): 46.2100 | Max. Longitudinal Feed Rate Per Revolution (mm): 0.20 |
| Minimum Metric Pitch (Decimal Inch): 10.0000 | Cross Slide Travel (Decimal Inch): 4.3300 |
| Number of Inch Threads: 8 | Number of Metric Threads: 12 |
| Tailstock Travel (mm): 65.00 | Spindle Taper Size: 4MT |
| Tailstock Taper Size: 2MT | Tailstock Travel (Decimal Inch): 2.5600 |
| Overall Height (Decimal Inch): 18.7000 | Top Slide Travel (mm): 70.00 |
| Maximum Cross Feed Rate Per Revolution (mm): 0.51 | Maximum Threads Per Inch: 44 |
| Min. Longitudinal Feed Per Rev. (Decimal Inch): 0.0039 | Swing Over Cross Slide (mm): 150.11 |
| Max. Longitudinal Feed Per Rev. (Decimal Inch): 0.0078 | Min. Cross Feed Rate Per Revolution (Decimal Inch): 0.001000 |
| Max. Cross Feed Rate Per Revolution (Decimal Inch): 0.0200 | Swing Over Cross Slide (Decimal Inch): 5.9100 |
| Swing Over Gap (Decimal Inch): 5.9100 | Swing Over Gap: 150.11 mm; 5.91 in |
| Country of Origin: China | |
| Lathe Type: Toolroom | |
| Horse Power: 1 | |
| Phase: Single | |
| Voltage: 115V | |
| Swing (Inch): 9 | |
| Bed Width (Inch): 9.0000 | |
| Spindle Speed Control: Geared Head | |
| Spindle Bore Diameter (mm): 26.00 | |
| Cross Slide Travel (mm): 109.98 | |
| Gap Length (Decimal Inch): 20.0000 | |
| Bed Width (Inch): 9 | |
| Gap Length (mm): 508.00 | |
| Maximum Metric Pitch (Decimal Inch): 12.0000 | |
| Overall Length (mm): 1250.00 | |
| Minimum Spindle Speed: 125 | |
| Maximum Spindle Speed (RPM): 2000 | |
| Overall Depth (Inch): 23 | |
| Overall Depth (Decimal Inch): 23.0000 | |
| Overall Depth (Mm): 584.20 | |
| Overall Height (mm): 475.00 | |
| Overall Length (Decimal Inch): 46.2100 | |
| Max. Longitudinal Feed Rate Per Revolution (mm): 0.20 | |
| Minimum Metric Pitch (Decimal Inch): 10.0000 | |
| Cross Slide Travel (Decimal Inch): 4.3300 | |
| Number of Inch Threads: 8 | |
| Number of Metric Threads: 12 | |
| Tailstock Travel (mm): 65.00 | |
| Spindle Taper Size: 4MT | |
| Tailstock Taper Size: 2MT | |
| Tailstock Travel (Decimal Inch): 2.5600 | |
| Overall Height (Decimal Inch): 18.7000 | |
| Top Slide Travel (mm): 70.00 | |
| Maximum Cross Feed Rate Per Revolution (mm): 0.51 | |
| Maximum Threads Per Inch: 44 | |
| Min. Longitudinal Feed Per Rev. (Decimal Inch): 0.0039 | |
| Swing Over Cross Slide (mm): 150.11 | |
| Max. Longitudinal Feed Per Rev. (Decimal Inch): 0.0078 | |
| Min. Cross Feed Rate Per Revolution (Decimal Inch): 0.001000 | |
| Max. Cross Feed Rate Per Revolution (Decimal Inch): 0.0200 | |
| Swing Over Cross Slide (Decimal Inch): 5.9100 | |
| Swing Over Gap (Decimal Inch): 5.9100 | |
| Swing Over Gap: 150.11 mm; 5.91 in | |
| Country of Origin: China |
| MSC# | 56852940 |
| Mfr# | 9684504 |
