Specifications
| Stand Type: Floor | Swing Distance (Decimal Inch): 20.8000 |
| Spindle Speed Control: Variable Speed | Phase: Single |
| Spindle Taper Size: 3MT | Maximum Spindle Speed (RPM): 2000 |
| Spindle to Table Distance (Inch): 33-1/2 | Spindle Travel Length (Decimal Inch): 5.9000 |
| Column Diameter (Decimal Inch): 4.5200 | Drilling Capacity in Steel (Inch): 1-1/16 |
| Drilling Capacity in Cast Iron (Inch): 1-1/16 | UNSPSC Code: 23241801 |
| Table Length (Decimal Inch): 22.0000 | Base Length: 27.0000 |
| Country of Origin: Taiwan | |
| Stand Type: Floor | |
| Swing Distance (Decimal Inch): 20.8000 | |
| Spindle Speed Control: Variable Speed | |
| Phase: Single | |
| Spindle Taper Size: 3MT | |
| Maximum Spindle Speed (RPM): 2000 | |
| Spindle to Table Distance (Inch): 33-1/2 | |
| Spindle Travel Length (Decimal Inch): 5.9000 | |
| Column Diameter (Decimal Inch): 4.5200 | |
| Drilling Capacity in Steel (Inch): 1-1/16 | |
| Drilling Capacity in Cast Iron (Inch): 1-1/16 | |
| UNSPSC Code: 23241801 | |
| Table Length (Decimal Inch): 22.0000 | |
| Base Length: 27.0000 | |
| Country of Origin: Taiwan |
| MSC# | 10755031 |
| Mfr# | 1227902 |
