Sale!
Indexable Boring Bar: A12S-SCLCR3, 23.60 mm Min Bore, Right Hand, 19.05 mm Shank Dia, 0.000 deg Lead Angle, Steel
Original price was: 267,00 $.122,89 $Current price is: 122,89 $.
Specifications
| Minimum Bore Diameter (mm): 23.60 | Minimum Bore Diameter (Decimal Inch): 0.9291 |
| Toolholder Style: A-SCLC | Tool Material: Steel |
| Insert Compatibility: CCMT 32.52 | Shank Diameter (mm): 19.05 |
| Shank Diameter (Inch): 3/4 | Hand of Holder: Right Hand |
| Overall Length (Decimal Inch): 10.0000 | Overall Length (mm): 254.00 |
| Overall Length (Inch): 10 | Minimum Bore Diameter Using Triangle Insert Cartridge (Decimal Inch): 0.9291 |
| Minimum Bore Diameter Using Diamond Insert Cartridge (Decimal Inch): 0.9291 | Insert Holding Method: Screw Clamping |
| Rake: Neutral | Rake Angle: 0.000 |
| Lead Angle: 0.000 | Series: CoroTurn 107 |
| Insert Inscribed Circle (Inch): 3/8 | Insert Inscribed Circle (Decimal Inch): 0.3750 |
| Insert Inscribed Circle (mm): 9.53 | Multi-use Tool: Yes |
| Back of Bar to Cutting Edge (Decimal Inch): 10.0000 | Back of Bar to Cutting Edge (mm): 254.00 |
| Center to Cutting Edge (Decimal Inch): 0.5000 | Center to Cutting Edge (Inch): 1/2 |
| Center to Cutting Edge (mm): 12.70 | Number of Inserts Used on Toolholder: 1 |
| Neck Diameter (Decimal Inch): 0.7500 | UNSPSC Code: 23241601 |
| Neck Diameter (Inch): 3/4 | Insert Thickness (Decimal Inch): 0.1563 |
| Insert Thickness (Inch): 5/32 | Manufacturers Catalog Number: A12S-SCLCR 3 |
| Coolant Through: Yes | Country of Origin: VARIOUS |
| Minimum Bore Diameter (mm): 23.60 | |
| Minimum Bore Diameter (Decimal Inch): 0.9291 | |
| Toolholder Style: A-SCLC | |
| Tool Material: Steel | |
| Insert Compatibility: CCMT 32.52 | |
| Shank Diameter (mm): 19.05 | |
| Shank Diameter (Inch): 3/4 | |
| Hand of Holder: Right Hand | |
| Overall Length (Decimal Inch): 10.0000 | |
| Overall Length (mm): 254.00 | |
| Overall Length (Inch): 10 | |
| Minimum Bore Diameter Using Triangle Insert Cartridge (Decimal Inch): 0.9291 | |
| Minimum Bore Diameter Using Diamond Insert Cartridge (Decimal Inch): 0.9291 | |
| Insert Holding Method: Screw Clamping | |
| Rake: Neutral | |
| Rake Angle: 0.000 | |
| Lead Angle: 0.000 | |
| Series: CoroTurn 107 | |
| Insert Inscribed Circle (Inch): 3/8 | |
| Insert Inscribed Circle (Decimal Inch): 0.3750 | |
| Insert Inscribed Circle (mm): 9.53 | |
| Multi-use Tool: Yes | |
| Back of Bar to Cutting Edge (Decimal Inch): 10.0000 | |
| Back of Bar to Cutting Edge (mm): 254.00 | |
| Center to Cutting Edge (Decimal Inch): 0.5000 | |
| Center to Cutting Edge (Inch): 1/2 | |
| Center to Cutting Edge (mm): 12.70 | |
| Number of Inserts Used on Toolholder: 1 | |
| Neck Diameter (Decimal Inch): 0.7500 | |
| UNSPSC Code: 23241601 | |
| Neck Diameter (Inch): 3/4 | |
| Insert Thickness (Decimal Inch): 0.1563 | |
| Insert Thickness (Inch): 5/32 | |
| Manufacturers Catalog Number: A12S-SCLCR 3 | |
| Coolant Through: Yes | |
| Country of Origin: VARIOUS |
| MSC# | 31835705 |
| Mfr# | 5721689 |
