Sale!
Indexable Threading Toolholder: Internal & External, Right Hand, 14.48 x 5/8″ Shank
Original price was: 281,00 $.140,99 $Current price is: 140,99 $.
Specifications
| Thread Type: Internal; External | Hand of Holder: Right Hand |
| Shank Width/Diameter (Decimal Inch): 0.6250 | Shank Width/Diameter (Inch): 5/8 |
| Toolholder Style: R166.0KF..C | Insert Compatibility: R166.0L to 11 |
| Insert Holding Method: Clamp & Screw | Shank Height (mm): 14.48 |
| Shank Height (Decimal Inch): 0.5700 | Shank Length (Inch): 5 |
| Shank Length (Decimal Inch): 5.0000 | Overall Length (Inch): 5 |
| Overall Length (Decimal Inch): 5.0000 | Minimum Bore Diameter (Decimal Inch): 0.5000 |
| Head Length (Decimal Inch): 0.8189 | Head Length (mm): 20.80 |
| Maximum Depth of Cut (Decimal Inch): 0.8189 | Back of Bar to Cutting Edge (Inch): 5 |
| Back of Bar to Cutting Edge (Decimal Inch): 5.0000 | Center to Cutting Edge (mm): 10.01 |
| Center to Cutting Edge (Decimal Inch): 0.3940 | Insert Inscribed Circle (Decimal Inch): 0.2500 |
| Insert Inscribed Circle (Inch): 1/4 | Neck Diameter (Decimal Inch): 0.6250 |
| UNSPSC Code: 23291800 | Toolholder Material: Steel |
| Coolant Through: No | Series: T-Max U-Lock |
| Country of Origin: India | |
| Thread Type: Internal; External | |
| Hand of Holder: Right Hand | |
| Shank Width/Diameter (Decimal Inch): 0.6250 | |
| Shank Width/Diameter (Inch): 5/8 | |
| Toolholder Style: R166.0KF..C | |
| Insert Compatibility: R166.0L to 11 | |
| Insert Holding Method: Clamp & Screw | |
| Shank Height (mm): 14.48 | |
| Shank Height (Decimal Inch): 0.5700 | |
| Shank Length (Inch): 5 | |
| Shank Length (Decimal Inch): 5.0000 | |
| Overall Length (Inch): 5 | |
| Overall Length (Decimal Inch): 5.0000 | |
| Minimum Bore Diameter (Decimal Inch): 0.5000 | |
| Head Length (Decimal Inch): 0.8189 | |
| Head Length (mm): 20.80 | |
| Maximum Depth of Cut (Decimal Inch): 0.8189 | |
| Back of Bar to Cutting Edge (Inch): 5 | |
| Back of Bar to Cutting Edge (Decimal Inch): 5.0000 | |
| Center to Cutting Edge (mm): 10.01 | |
| Center to Cutting Edge (Decimal Inch): 0.3940 | |
| Insert Inscribed Circle (Decimal Inch): 0.2500 | |
| Insert Inscribed Circle (Inch): 1/4 | |
| Neck Diameter (Decimal Inch): 0.6250 | |
| UNSPSC Code: 23291800 | |
| Toolholder Material: Steel | |
| Coolant Through: No | |
| Series: T-Max U-Lock | |
| Country of Origin: India |
| MSC# | 56145907 |
| Mfr# | 5742013 |
