Indexable Turning Toolholder: DDJNR & L164DKC3, Clamp
136,89 $
Specifications
| Toolholder Style: DDJN | Hand of Holder: Right Hand |
| Insert Compatibility: DN..43. | Insert Holding Method: Clamp |
| Shank Width (Inch): 1 | Shank Height (Inch): 1 |
| Overall Length (Decimal Inch): 6.0000 | Shank Height (mm): 25.40 |
| Coolant Through: No | Rake: Negative |
| Multi-use Tool: No | Shank Width (Decimal Inch): 1.0000 |
| Shank Height (Decimal Inch): 1.0000 | Series: Kenclamp |
| Overall Length (Inch): 6 | Head Length (Decimal Inch): 1.2500 |
| Head Length (mm): 31.75 | Back of Bar to Cutting Edge (Decimal Inch): 1.2500 |
| Back of Bar to Cutting Edge (mm): 31.75 | Insert Inscribed Circle (Decimal Inch): 0.5000 |
| Insert Inscribed Circle (Inch): 1/2 | Toolholder Material: Steel |
| Complete Insert Compatibility: DN.. 432 | UNSPSC Code: 23153308 |
| Manufacturers Catalog Number: DDJNR; L164DKC3 | Country of Origin: Bulgaria |
| Toolholder Style: DDJN | |
| Hand of Holder: Right Hand | |
| Insert Compatibility: DN..43. | |
| Insert Holding Method: Clamp | |
| Shank Width (Inch): 1 | |
| Shank Height (Inch): 1 | |
| Overall Length (Decimal Inch): 6.0000 | |
| Shank Height (mm): 25.40 | |
| Coolant Through: No | |
| Rake: Negative | |
| Multi-use Tool: No | |
| Shank Width (Decimal Inch): 1.0000 | |
| Shank Height (Decimal Inch): 1.0000 | |
| Series: Kenclamp | |
| Overall Length (Inch): 6 | |
| Head Length (Decimal Inch): 1.2500 | |
| Head Length (mm): 31.75 | |
| Back of Bar to Cutting Edge (Decimal Inch): 1.2500 | |
| Back of Bar to Cutting Edge (mm): 31.75 | |
| Insert Inscribed Circle (Decimal Inch): 0.5000 | |
| Insert Inscribed Circle (Inch): 1/2 | |
| Toolholder Material: Steel | |
| Complete Insert Compatibility: DN.. 432 | |
| UNSPSC Code: 23153308 | |
| Manufacturers Catalog Number: DDJNR; L164DKC3 | |
| Country of Origin: Bulgaria |
| MSC# | 64922982 |
| Mfr# | 1875136 |
| Big Book# | 831 |
